using System;
using System.Collections.Generic;
using System.Text;
using System.IO;
using System.Data.Odbc; //add by hand,which is needed when load the layer attribute information
using System.Data.OleDb;
using System.Collections;
using System.Data;
using System.Xml;
namespace CGCL.CGFiles
{
public class CGShapeFileParser
{
public class ESRI_ShxHeader
{
int FileCode; //9994
int[] Unused2 = new int[5];
int FileLength;
int Version; //1000
int ShapeType; // 0- Null shape
// 1- Point
// 3-Arc
// 5-Polygon
// 8-MultiPoint
double XMin;
double YMin;
double XMax;
double YMax;
int[] Unused3 = new int[8];
}
class ESRI_ShapeFile
{
int FileCode; //9994
int[] Unused = new int[5];
int FileLength;
int Version; //1000
int ShapeType; // 0- Null shape
// 1- Point
// 3-Arc
// 5-Polygon
// 8-MultiPoint
double XMin;
double YMin;
double XMax;
double YMax;
int[] Unused1 = new int[8];
}
class ESRI_RecordHeader
{
int RecNumber;
int ContentLength;
}
class ESRI_PointContent
{
int ShapeType;
double X;
double Y;
}
class ESRI_IndexRec//索引文件
{
int Offset;
int ContentLen;
}
class ESRI_ArcContent
{
int ShapeType;
double xmin;
double ymin;
double xmax;
double ymax;
int NumParts;
int NumPoints;
}
class ESRI_PolygonContent
{
int ShapeType;
double xmin;
double ymin;
double xmax;
double ymax;
int NumParts;
int NumPoints;
}
public bool LoadShapeFile(CGDataAdapter.CGLocalGeoDataAdapter adapter)
{
string connectionString;
OdbcConnection connection;
OdbcDataAdapter OdbcAdapter;
CGMap.CGGeoLayer geolayer = adapter.getMasterGeoLayer();
string shpfilepath = adapter.getPath();
string shpfilename = adapter.getFileName();
string shxfilepath = shpfilepath.Substring(0, shpfilepath.LastIndexOf("\\") + 1) + adapter.getFileName() + ".shx";
//read out the layer attribute infomation
connectionString = "Dsn=Visual FoxPro Database;sourcedb=" + shpfilepath + ";sourcetype=DBF;exclusive=No;backgroundfetch=Yes;collate=Machine";
connection = new OdbcConnection(connectionString);
connection.Open();
OdbcAdapter = new OdbcDataAdapter("select * from " + shpfilename, connectionString);
// Create new DataTable and DataSource objects.
DataSet ds = new DataSet();
OdbcAdapter.Fill(ds);
connection.Close();
if (geolayer == null) return false;
try
{
//先读取.shx文件,得到文件的总字节长度
FileStream fs = new FileStream(shxfilepath, FileMode.Open, FileAccess.Read); //文件流形式
BinaryReader BinaryFile = new BinaryReader(fs); //二进制读取文件的对象
long BytesSum = fs.Length; //得到文件的字节总长
int shapecount = (int)(BytesSum - 100) / 8; //得以总记录数目
BinaryFile.Close();
fs.Close();
//打开shp文件
if (shxfilepath == "")
{
// MessageBox.Show("索引文件打开出错");
return false;
}
//打开.shp文件,读取x,y坐标的信息
fs = new FileStream(shpfilepath, FileMode.Open, FileAccess.Read); //文件流形式
BinaryFile = new BinaryReader(fs); //打开二进制文件
BinaryFile.ReadBytes(32); //先读出36个字节,紧接着是Box边界合
int shapetype = BinaryFile.ReadInt32();
geolayer.envlope.left = BinaryFile.ReadDouble(); //读出整个shp图层的边界合
geolayer.envlope.bottom = BinaryFile.ReadDouble();
geolayer.envlope.right = BinaryFile.ReadDouble();
geolayer.envlope.top = BinaryFile.ReadDouble();
BinaryFile.ReadBytes(32); // shp中尚未使用的边界盒
//Get Shape Data From Here On
int stype;
double x, y;
double left, right, top, bottom;
int partcount;
int pointcount;
switch (shapetype)
{
case 1://single point
geolayer.shapeType = CGConstants.CGShapeType.SHAPE_POINT;
for (int i = 0; i < shapecount; i++)
{
CGGeoShape.CGGeoPoint gps = new CGGeoShape.CGGeoPoint();
BinaryFile.ReadBytes(12); //记录头8个字节和一个int(4个字节)的shapetype
/* stype = BinaryFile.ReadInt32();
if (stype != shapetype)
continue;
*/
x = BinaryFile.ReadDouble();
y = BinaryFile.ReadDouble();
gps.objectID = i;
gps.objectUID = i;
gps.x = x;
gps.y = y;
gps.z = 0;
gps.envlope.left = gps.x;
gps.envlope.right = gps.x;
gps.envlope.top = gps.y;
gps.envlope.bottom = gps.y;
geolayer.getDataContainer().Add(gps);
}
break;
case 8://multi points layer
break;
case 3://Polyline layer
geolayer.shapeType = CGConstants.CGShapeType.SHAPE_LINE;
for (int i = 0; i < shapecount; i++)
{
geolayer.getAttributeContainer().Add(ds.Tables[0].Rows[i][0]); //read out the attribute step by step
BinaryFile.ReadBytes(12);
// int pos = indexRecs[i].Offset+8;
// bb0.position(pos);
// stype = bb0.getInt();
// if (stype!=nshapetype){
// continue;
// }
left = BinaryFile.ReadDouble();
bottom = BinaryFile.ReadDouble();
right = BinaryFile.ReadDouble();
top = BinaryFile.ReadDouble();
partcount = BinaryFile.ReadInt32();
pointcount = BinaryFile.ReadInt32();
int[] parts = new int[partcount];
int[] partspos = new int[partcount];
double[] xpoints = new double[pointcount];
double[] ypoints = new double[pointcount];
double[] zpoints = new double[pointcount];
//firstly read out parts begin pos in file
for (int j = 0; j < partcount; j++)
{
parts[j] = BinaryFile.ReadInt32();
}
//shift them to be points count included in parts
if (partcount > 0)
partspos[0] = 0;
int newpos = 0;
for (int j = 0; j <= partcount - 2; j++)
{
parts[j] = parts[j + 1] - parts[j];
newpos += parts[j];
partspos[j + 1] = newpos;
}
parts[partcount - 1] = pointcount - parts[partcount - 1];
//read out coordinates
for (int j = 0; j < pointcount; j++)
{
x = BinaryFile.ReadDouble();
y = BinaryFile.ReadDouble();
xpoints[j] = x;
ypoints[j] = y;
zpoints[j] = 0;
}
if (pointcount > 1)
{
CGGeoShape.CGGeoLine gl = new CGGeoShape.CGGeoLine(xpoints, ypoints, zpoints, parts, partspos, pointcount, partcount);
gl.envlope.left = left;
gl.envlope.right = right;
gl.envlope.top = top;
gl.envlope.bottom = bottom;
gl.objectID = i;
gl.objectUID = i;
geolayer.getDataContainer().Add(gl);
}
}
break;
case 5://Polygon layer
geolayer.shapeType = CGConstants.CGShapeType.SHAPE_POLYGON;
for (int i = 0; i < shapecount; i++)
{
geolayer.getAttributeContainer().Add(ds.Tables[0].Rows[i][0]);
/* bb0.rewind();
bb0.position(indexRecs[i].Offset + 8);
stype = BinaryFile.ReadInt32();
if (stype != shapetype)
{
continue;
}*/
BinaryFile.ReadBytes(12);
left = BinaryFile.ReadDouble();
bottom = BinaryFile.ReadDouble();
right = BinaryFile.ReadDouble();
top = BinaryFile.ReadDouble();
partcount = BinaryFile.ReadInt32();
pointcount = BinaryFile.ReadInt32();
int[] parts = new int[partcount];
int[] partspos = new int[partcount];
double[] xpoints = new double[pointcount];
double[] ypoints = new double[pointcount];
double[] zpoints = new double[pointcount];
//firstly read out parts begin pos in file
for (int j = 0; j < partcount; j++)
{
parts[j] =BinaryFile.ReadInt32();
}
//shift them to be points count included in parts
if (partcount > 0)
partspos[0] = 0;
int newpos = 0;
for (int j = 0; j <= partcount - 2; j++)
{
parts[j] = parts[j + 1] - parts[j];
newpos += parts[j];
partspos[j + 1] = newpos;
}
parts[partcount - 1] = pointcount - parts[partcount - 1];
//read out coordinates
for (int j = 0; j < pointcount; j++)
{
x = BinaryFile.ReadDouble();
y = BinaryFile.ReadDouble();
xpoints[j] = x;
ypoints[j] = y;
zpoints[j] = 0;
}
if (pointcount > 1)
{
CGGeoShape.CGGeoPolygon gl = new CGGeoShape.CGGeoPolygon(xpoints, ypoints, zpoints, parts, partspos, pointcount, partcount);
gl.envlope.left = left;
gl.envlope.right = right;
gl.envlope.top = top;
gl.envlope.bottom = bottom;
gl.objectID = i;
gl.objectUID = i;
geolayer.getDataContainer().Add(gl);
}
}
break;
default:
return false;
}
}
catch (FileNotFoundException e)
{
e.ToString();
}
/*
cgClsLib.cgMapStock.cgGeoLayer geolayer = adapter.getMasterGeoLayer();
if (geolayer==null)
return false;
try{
// build stream connection
String fullname = adapter.getPath()+adapter.getFileName();
String idxfilename = fullname.Substring(0,fullname.LastIndexOf("\\"))+".shx";
FileInputStream in00 = new FileInputStream(fullname);
ByteBuffer bb0 = ByteBuffer.allocate(in00.available());
in00.read(bb0.array());
bb0.order(ByteOrder.LITTLE_ENDIAN);
in00 = null;
FileInputStream in10 = new FileInputStream(idxfilename);
ByteBuffer bb1 = ByteBuffer.allocate(in10.available());
in10.read(bb1.array());
bb1.order(ByteOrder.LITTLE_ENDIAN);
in10 = null;
int shapecount = (bb1.capacity()-100)/8;
//Get Shape Index Information
ESRI_IndexRec[] indexRecs = new ESRI_IndexRec[shapecount];
bb1.position(100);
for( int ii = 0 ; ii< shapecount; ii++)
{
indexRecs[ii] = new ESRI_IndexRec();
indexRecs[ii].Offset = bb1.getInt();
indexRecs[ii].ContentLen = bb1.getInt();
indexRecs[ii].Offset=((indexRecs[ii].Offset<<24&0xff000000)|(indexRecs[ii].Offset<<8 &0x00ff0000)|(indexRecs[ii].Offset>>8 &0x0000ff00)|(indexRecs[ii].Offset>>24&0x000000ff))<<1;
}
//Get Shape Outline Information
bb0.position(32);
int nshapetype = bb0.getInt();
geolayer.envlope.left = BinaryFile.ReadDouble();();
geolayer.envlope.bottom = BinaryFile.ReadDouble();();
geolayer.envlope.right = BinaryFile.ReadDouble();();
geolayer.envlope.top =BinaryFile.ReadDouble();();
//Get Shape Data From Here On
int stype;
double x , y ;
double left, right, top, bottom;
int partcount;
int pointcount;
switch(nshapetype){
case 1://single point
geolayer.shapeType = MKShapeType.SHAPE_POINT;
for(int i=0; i<shapecount; i++){
MKGeoPoint gps = new MKGeoPoint();
bb0.position(indexRecs[i].Offset+8);
stype = bb0.getInt();
x = BinaryFile.ReadDouble();();
y = BinaryFile.ReadDouble();();
if (stype!=nshapetype)
continue;
gps.objectID = i;
gps.objectUID = i;
gps.x = x;
gps.y = y;
gps.z = 0;
gps.envlope.left = gps.x;
gps.envlope.right = gps.x;
gps.envlope.top = gps.y;
gps.envlope.bottom = gps.y;
geolayer.getDataContainer().add(gps);
}
break;
case 8://multi points layer
break;
case 3://Polyline layer
geolayer.shapeType = MKShapeType.SHAPE_LINE;
for(int i=0; i<shapecount; i++){
int pos = indexRecs[i].Offset+8;
bb0.position(pos);
stype = bb0.getInt();
if (stype!=nshapetype){
continue;
}
left = BinaryFile.ReadDouble();();
bottom = BinaryFile.ReadDouble();();
right = BinaryFile.ReadDouble();();
top = BinaryFile.ReadDouble();();
partcount = bb0.getInt();
pointcount = bb0.getInt();
int[] parts = new int[partcount];
int[] partspos = new int[partcount];
double[] xpoints = new double[pointcount];
double[] ypoints = new double[pointcount];
double[] zpoints = new double[pointcount];
//firstly read out parts begin pos in file
for(int j = 0; j < partcount;j++){
parts[j]= bb0.getInt();
}
//shift them to be points count included in parts
if (partcount > 0)
partspos[0]=0;
int newpos=0;
for(int j = 0; j <= partcount-2;j++){
parts[j]= parts[j+1] - parts[j];
newpos+=parts[j];
partspos[j+1]=newpos;
}
parts[partcount-1]=pointcount-parts[partcount-1];
//read out coordinates
for(int j = 0 ; j < pointcount;j++){
x= BinaryFile.ReadDouble();();
y= BinaryFile.ReadDouble();();
xpoints[j] = x;
ypoints[j] = y;
zpoints[j] = 0;
}
if (pointcount > 1){
cgClsLib.cgGeoObject.cgGeoLine gl = new cgClsLib.cgGeoObject.cgGeoLine(xpoints,ypoints,zpoints,parts,partspos,pointcount,partcount);
gl.envlope.left = left;
gl.envlope.right = right;
gl.envlope.top = top;
gl.envlope.bottom = bottom;
gl.objectID = i;
gl.objectUID = i;
geolayer.getDataContainer().add(gl);
}
}
break;
case 5://Polygon layer
geolayer.shapeType = MKShapeType.SHAPE_POLYGON;
for(int i=0; i<shapecount; i++){
bb0.rewind();
bb0.position(indexRecs[i].Offset+8);
stype = bb0.getInt();
if (stype!=nshapetype){
continue;
}
left = BinaryFile.ReadDouble();();
bottom = BinaryFile.ReadDouble();();
right = BinaryFile.ReadDouble();();
top = BinaryFile.ReadDouble();();
partcount = bb0.getInt();
pointcount = bb0.getInt();
int[] parts = new int[partcount];
int[] partspos = new int[partcount];
double[] xpoints = new double[pointcount];
double[] ypoints = new double[pointcount];
double[] zpoints = new double[pointcount];
//firstly read out parts begin pos in file
for(int j = 0; j < partcount;j++){
parts[j]= bb0.getInt();
}
//shift them to be points count included in parts
if (partcount > 0)
partspos[0]=0;
int newpos=0;
for(int j = 0; j <= partcount-2;j++){
parts[j]= parts[j+1] - parts[j];
newpos+=parts[j];
partspos[j+1]=newpos;
}
parts[partcount-1]=pointcount-parts[partcount-1];
//read out coordinates
for(int j = 0 ; j < pointcount;j++){
x= BinaryFile.ReadDouble();();
y= BinaryFile.ReadDouble();();
xpoints[j] = x;
ypoints[j] = y;
zpoints[j] = 0;
}
if (pointcount>1){
MKGeoPolygon gl = new MKGeoPolygon(xpoints,ypoints,zpoints,parts,partspos,pointcount,partcount);
gl.envlope.left = left;
gl.envlope.right = right;
gl.envlope.top = top;
gl.envlope.bottom = bottom;
gl.objectID = i;
gl.objectUID = i;
geolayer.getDataContainer().add(gl);
}
}
break;
default :
// System.out.println(NotifyMessages.NO_SUCHTYPE);
return false;
}
}
catch(FileNotFoundException e){
return false;
}
catch(EOFException e2){
return false;
}
catch(IOException e1){
return false;
}
catch(Exception e){
return false;
}*/
return true;
}
public bool SaveShapeFile(CGDataAdapter.CGLocalGeoDataAdapter adapter)
{
return true;
}
}
}
