生成3波段Raster图像（C#+Engine）

       目前只能生成3个波段。当波段大于3时会出问题。

       public void CreateMultBandsRaster(string directoryName)//, string szFile, string szRasFormat /*= "IMAGINE Image"*/

        {

            Random random=new Random ();

            if (File.Exists("d:\\vge.img"))

            {

                File.Delete("d:\\vge.img");

            }

            IWorkspaceFactory m_WorkspaceFactory = new RasterWorkspaceFactoryClass();

            IRasterDataset m_RasterDataSet=null;

            IPoint originPoint = new PointClass();

            originPoint.PutCoords(0, 0);

            IRasterWorkspace2 m_RasterWorkspace2 = m_WorkspaceFactory.OpenFromFile("d:\\", 0) as IRasterWorkspace2;

            IProjectedCoordinateSystem m_ProjectedCoordinateSystem;

            ISpatialReferenceFactory2 spatRefFact = new SpatialReferenceEnvironmentClass();

            m_ProjectedCoordinateSystem = spatRefFact.CreateProjectedCoordinateSystem((int)esriSRProjCSType.esriSRProjCS_WGS1984UTM_49N);

            m_RasterWorkspace2 = createRasterWorkspace(directoryName);

            m_RasterDataSet = m_RasterWorkspace2.CreateRasterDataset("vge.img", "IMAGINE Image", originPoint, 10,10, 1, 1, 6, rstPixelType.PT_UCHAR, m_ProjectedCoordinateSystem, true);

             IRaster m_Raster;

             RasterInfo rstInfo = new RasterInfo();

             rstInfo.lNumbands = 6;

             IRawPixels []m_RawPixels = new IRawPixels[rstInfo.lNumbands];

             m_Raster = m_RasterDataSet.CreateDefaultRaster();

             IRasterProps m_RasterProps = m_Raster as IRasterProps;

             // Get RasterBand from the raster

             IRasterBandCollection m_RasterBandCollection = m_Raster as IRasterBandCollection;

             IPixelBlock3[] m_PixelBlock = new IPixelBlock3[rstInfo.lNumbands];

             for (int i = 0; i < rstInfo.lNumbands; i++)

             {

                 m_RawPixels[i] = (IRawPixels)m_RasterBandCollection.Item(i);

             }

      /* */

             //目前这个设置透明色值不管用，不知道正确的方法是怎么样

             /*if (bNoDataValue > 0 &#124;&#124; bNoDataValue < 256) {

              VARIANT vVal;

              vVal.vt = VT_UI1;

              vVal.cVal = bNoDataValue;

             // ipRasProps->put_NoDataValue(vVal);

              ipRasProps->put_NoDataValue(CComVariant(bNoDataValue));

             }

             */// QI RawPixel interface

             m_RasterProps = m_Raster as IRasterProps;

             // Create a DblPnt to hold the PixelBlock size

             IPnt m_PixelBlockSize=new DblPntClass();

             long lWidth, lHeight;

             lWidth=m_RasterProps.Width;

             lHeight = m_RasterProps.Height;

             m_PixelBlockSize.SetCoords(lWidth, lHeight);

             // Create PixelBlock with defined size

             IPnt pixelBlockOrigin = new DblPntClass();

             pixelBlockOrigin.SetCoords(0, 0);

            System.Array[] pixelData = new System.Array[rstInfo.lNumbands];

            for (int i = 0; i < rstInfo.lNumbands; i++)

            {

                m_PixelBlock[i] =(IPixelBlock3)m_RawPixels[i].CreatePixelBlock(m_PixelBlockSize);//When There is more than 3 bands, error happens here.

                pixelData[i] = (System.Array)m_PixelBlock[i].get_PixelDataByRef(0);

                for (int ii = 0; ii < m_RasterProps.Width; ii++)

                    for (int jj = 0; jj < m_RasterProps.Height; jj++)

                    {

                        if (i == 0)

                            pixelData[i].SetValue(Convert.ToByte((ii*jj)%255), ii, jj);

                        else if (i == 1)

                        {

                            if((ii*jj)%255>130)

                                pixelData[i].SetValue(Convert.ToByte((ii * jj) % 255-130), ii, jj);//random.Next(100,110)

                            else

                                pixelData[i].SetValue(Convert.ToByte(130-(ii * jj) % 255), ii, jj);//random.Next(100,110)

                        }

                        else

                            pixelData[i].SetValue(Convert.ToByte(255 - (ii * jj) % 255), ii, jj);

                    }

                m_PixelBlock[i].set_PixelData(0, (System.Object)pixelData[i]);

                System.Object cachePointer;

                cachePointer = m_RawPixels[i].AcquireCache();

               m_RawPixels[i].Write(pixelBlockOrigin, (IPixelBlock)m_PixelBlock[i]);

                m_RawPixels[i].ReturnCache(cachePointer);

            }

            IRasterLayer pRasterLayer = new RasterLayerClass();

            pRasterLayer.CreateFromDataset(m_RasterDataSet);

            ILayer pLayer;

            pLayer = pRasterLayer;

            pLayer.Name = "New Raster";

            axMapControl1.Map.AddLayer(pLayer);

            axMapControl1.ActiveView.Refresh();

        }
